TRL 1630SX Toolroom Lathe
TRL 1630SX Toolroom Lathe
TRL 1630SX Toolroom Lathe
TRL 1630SX Features
• 16″ swing, 30″ between centers
• Spindle through hole of 2.12″
• 150-2500 rpm Specifications
1630SX Capacity Height of Centers 8″
Distance between centers 30″
Swing over bed 16″
Swing Over Saddle Wings 16″
Swing Over Cross Slide 8.6″
Cross Slide Travel 8.5″
Tool Section Max 3/4″
Coolant Reservoir Capacity 9.3 gal.
Head Stock Lubrication Oil Bath
Rapid Speeds 150 Ipm. on Z Axis 100 Ipm. on X Axis
Width of Bed 12.6″
Height Of Bed 12.6″
Headstock Spindle Nose D1-6
Spindle Through Hole 2.12″
Spindle Taper MT#6 Taper in Reduction Sleeve
1 Spindle Speed Range RPM 150-2500
Quill Travel 6.3″
Quill Diameter 2.36″
Quill Taper Hole MT#4
Spindle Motor Horsepower 7.5 HP
Trak K3
TRL 1630SX Toolroom Lathe
TRL 1630SX Toolroom Lathe
Table Size 50″ x 10″
T-Slots (Number x Width) 3 x .625″ x 2.5″
Table Travel 32″
Saddle Travel 16″
Knee Travel 16″
RAM Travel 15″
Maximum Quill Travel 5″
Quill Diameter 3.375″
Spindle Taper R8
Spindle Speed Range RPM 60-500, 600-4200
Head Tilt 45° forward and back, 90° left and right
Quill Feeds per Revolution of Spindle 0.0015/0.003/0.006″
Spindle Motor HP 3 HP
Maximum Weight of Workpiece 850 lbs.
Dimensions 71″ (length) x 59″ (width) x 84″ (height)
Rapid Speeds 100 IPM X, Y Way Surface Type Dovetail X/Z, Square Y
Mazak VMC 410A-II
TRL 1630SX Toolroom Lathe
Mazak VMC 410A-II
Capacity
Table Right/Left 900 mm / 35.430 in Table Longitudinal 430 mm / 16.140 in
Spindle
Spindle Taper 40 Maximum Speed 12000 rpm Motor Output (30minute rating) 11 kw / 15.0 hp
Magazine
Number of Tools 30
Feed Axes
Travel (X Axis) 560 mm / 22.05 in
Travel (Y Axis) 410 mm / 16.14 in
Travel (Z Axis) 510 mm / 20.08 in
Surface Grinding
50- Watt Fiber Laser
Mazak VMC 410A-II
Capacity:
Chucking Length: 21.6"
Width: 10"
Travels:
X-Longitudinal: 20"
Y-Cross: 10"
Equipped With:
10" x 20" Electro-Magnetic Chuck
De-Magnetizer
Coolant
Automatic Wheel Dresser
Keyence XM-1500 CMM
50- Watt Fiber Laser
50- Watt Fiber Laser
Measuring unit
Infrared Measuring range 300 mm × 250 mm × 150 mm 11.81" × 9.84" × 5.91" 600 mm × 300 mm × 200 mm 23.62" × 11.81" × 7.87" Min. Display unit
Distance 1 μm Angle 0.0001 degrees Measurement accuracy
Repeatability Stage locked ±3 μm ±3 μm Stage unlocked - ±4 μm Indication error Stage locked ±8 μm*1 ±8 μm*1 Stage unlocked - ± (10 + L/100) μm*2 Stage Withstand load 25 kg X-axis movable range - ±100 mm ±3.94" Rotation range - ±60°
50- Watt Fiber Laser
50- Watt Fiber Laser
50- Watt Fiber Laser
50-Watt Fiber Laser
Engraving
Label Making
Photo/Picture Transfer
Materials
Metals, Plastics, Paper, Wood, Plastic, Firearms
Reverse Engineering
Reverse Engineering
Reverse Engineering
We Offer
Complete Auto Desk Suite
Cad Drawings
Prints
Product Planning & Manufacture.
